GTS5.2C

13 cm (5.25") Component System

Information

The CRUNCH GTS series offers top sound, good efficiency and easy installation! The good performance is due, among other things, to the use of expensive Y30 magnets, which, even with a smaller size, outperform some optically larger specimens. The GTS loudspeakers are also up-to-date in other respects: the spiders are additionally ventilated and the compos have an additional pole core bore for even better cooling. For the cone, the developers opted for a polypropylene version, which delivers the best results in terms of sound. Due to the linear frequency response of the loudspeakers, it is possible to use very small cable crossovers, which are designed separately for the tweeter and woofer.

Features

Sturdy Steels Baskets with moderate Installation Depth
Y30 Magnet Drivers
Polypropylen Cones
Sturdy Speaker Grilles
Separate Crossovers for Tweeters and Midbass
Tweeter crossover with High-Frequency Attenuation

Specifications

2 x 130 mm Midbass
4 x Inline Crossover
2 x 20 mm ​Silk Dome Neodymium Tweeter
Power Rating 80 Watts RMS
Power Rating 160 Watts MAX
Impedance 3 Ω
Frequency Range 65 - 22000 Hz
Installation Opening 117 mm
Installation Depth 50 mm

Downloads

Instruction Guide

€ 89,90

Manufacturer's suggested retail price.
Technical changes and mistakes reserved.
